Product Certifications
101
Product Certifications
March 2017
Reference Manual
00809-0100-4108, Rev CA
Special Conditions for Safe Use (X):
1. The enclosure may be made of aluminum alloy and
given a protective polyurethane paint finish; however,
care should be taken to protect it from impact or
abrasion if located in a zone 0 environment.
2. This apparatus is not capable of withstanding the
500 V r.m.s. insulation test required by Clause 6.3.12
of GB3836.4-2010.
3. The ambient temperature is:
4. Intrinsically safe parameters:
5. The product should be used with Ex-certified linear
associated apparatus to establish explosion
protection system that can be used in explosive gas
atmospheres. Wiring and terminals should comply
with the instruction manual of the product and
associated apparatus.
6. The cables between this product and associated
apparatus should be shielded cables (the cables must
have insulated shields). The shield has to be grounded
reliably in a non-hazardous area.
7. End users are not permitted to change any internal
components, but to settle the problem in conjunction
with the manufacturer to avoid damage to the
product.
8. During installation, use and maintenance of this
product, observe the following standards:
GB3836.13-2013, GB3836.15-2000,
GB3836.16-2006, G3836.18-2010, GB50257-2014.
B.2.7 Technical Regulations
Customs Union (EAC)
EM EAC Flameproof
Certificate: RU C-US.GB05.B.01197
Markings: Ga/Gb Ex d IIC T4/T6 X,
T4(-40 °C
≤ T
a
≤ +80 °C),
T6(-40 °C ≤ T
a
≤+40 °C)
Special Condition for Safe Use (X):
See certificate for special conditions.
IM EAC Intrinsically Safe
Certificate: RU C-US.GB05.B.01197
Markings: 0Ex ia IIC T4 Ga X (-55 °C
≤ T
a
≤ +70 °C)
Special Conditions for Safe Use (X):
See certificate for special conditions.
B.2.8 Combinations
K1 Combination of ED, I1, ND, and N1
K5 Combination of E5 and I5
K6 Combination of C6, ED, and I1
K7 Combination of E7, I7, NK, and N7
KB Combination of K5 and C6
KM Combination of EM and IM
KH Combination of ED, I1, and K5
B.2.9 Conduit plugs and
adapters
IECEx Flameproof and Increased Safety
Certificate: IECEx FMG 13.0032X
Standards: IEC60079-0:2011, IEC60079-1:2007,
IEC60079-7:2006-2007
Markings: Ex de IIC Gb
ATEX Flameproof and Increased Safety
Certificate: FM13ATEX0076X
Standards: EN60079-0:2012, EN60079-1:2007,
EN60079-7:2007
Markings: II 2 G Ex de IIC Gb
T
a
Temperature class
–55 °C ≤ T
a
≤ 70 °C T4
Parameter
HART
Voltage U
i
30 V
Current I
i
200 mA
Power P
i
0.9 W
Capacitance C
i
0.012 μF
Inductance L
i
0 mH
Table 11. Conduit Plug Thread Sizes
Thread Identification mark
M20 1.5 M20
1
/2–14 NPT
1
/2 NPT
G
1
/2A G
1
/2
