Rosemount 2088 - Process Connections; Inline Process Connection

37
Reference Manual
00809-0100-4108, Rev CA
Hardware Installation
March 2017
Hardware Installation
The best location for the transmitter in relation to the process pipe is dependent on the
process. Use the following guidelines to determine transmitter location and placement of
impulse piping:
 Keep impulse piping as short as possible.
 For liquid service, slope the impulse piping at least 1 in./ft (8 cm/m) upward from the
transmitter toward the process connection.
 For gas service, slope the impulse piping at least 1 in./ft (8 cm/m) downward from the
transmitter toward the process connection.
 Avoid high points in liquid lines and low points in gas lines.
 Use impulse piping large enough to avoid friction effects and blockage.
 Vent all gas from liquid piping legs.
 When purging, make the purge connection close to the process taps and purge through
equal lengths of the same size pipe. Avoid purging through the transmitter.
 Keep corrosive or hot [above 250 °F (121 °C)] process material out of direct contact with
the sensor module and flanges.
 Prevent sediment deposits in the impulse piping.
 Avoid conditions that might allow process fluid to freeze within the process flange.
3.4.3 Process connections
3.4.4 Inline process connection
Inline gage transmitter orientation
The low side pressure port on the inline gage transmitter is located in the neck of the
transmitter, behind the housing. The vent path is 360 degrees around the transmitter
between the housing and sensor (See Figure 3-7).
Keep the vent path free of any obstruction, such as paint, dust, and lubrication by mounting
the transmitter so that the process can drain away.
Interfering or blocking the atmospheric reference port will cause the transmitter to output
erroneous pressure values.
