Rosemount 2088 - Transient Protection (Option Code T1); Functional Specifications; Service; Pressure Range Values

Specifications and Reference Data
March 2017
Reference Manual
00809-0100-4108, Rev CA
Specifications and Reference Data
74
Rosemount 2090F and 2090P
Less than ±0.1% of upper range limit when subjected to
vibration of peak to peak constant displacement of 4 mm
(5–15 Hz) and constant acceleration of 2 g (15–150 Hz) and
1 g (150–2000 Hz)
Power supply effect
Less than ±0.005% of calibrated span per volt.
Electromagnetic Compatibility (EMC)
Meets all industrial environmental requirements of
EN61326 and NAMUR NE-21
(1)
. Maximum deviation < 1%
Span during EMC disturbance
(2)
.
A.1.7 Transient protection (option
code T1)
Tested in accordance with IEEE C62.41.2-2002,
Location Category B
6 kV crest (0.5 microseconds – 100 kHz)
3 kA crest (8  20 microseconds
6 kV crest (1.2  50 microseconds)
A.2 Functional specifications
A.2.1 Service
A.3 Pressure range values
A.3.1 Output protocols
A.3.2 4-20mA selectable HART
protocol (output code S)
Power supply
External power supply required. Standard transmitter
operates on 10.5 to 42.4 Vdc with no load.
1. NAMUR NE-21 does not apply to Low-power (transmitter option code N).
2. During surge event device may exceed maximum EMC deviation limit or reset;
however, device will self-recover and return to normal operation within speci-
fied start-up time.
Model Ambient temperature effects
Rosemount
2088
Liquid, gas, and vapor applications
Rosemount
2090F
Liquid, gas, vapor, and high-viscosity applications.
Rosemount
2090P
Liquid, gas, vapor, and high-viscosity applications.
Table A-1. Range Values for Rosemount 2088
Range
Minimum
span
URL
LRL
2088A 2088G
10.60 psi
(41,37 mbar)
30.00 psi
(2,07 bar)
0 psia
(0 bar)
–14.70 psig
(–1.01 bar)
23.00 psi
(206,85 mbar)
150.00 psi
(10,34 bar)
0 psia
(0 bar)
–14.70 psig
(–1.01 bar)
3 16.00 psi
(11,11 bar)
800.00 psi
(55,16 bar)
0 psia
(0 bar)
–14.70 psig
(–1.01 bar)
4 80.00 psi
(5,52 bar)
4000.00 psi
(275,79 bar)
0 psia
(0 bar)
–14.70 psig
(–1.01 bar)
Table A-2. Range Values for Rosemount 2090F and
2090P
Range
Minimum
span
URL
LRL
Absolute
Gage
11.5 psi
(103 mbar)
30.00 psi
(2,07 bar)
0 psia
(0 bar)
–14.70 psig
(–1.01 bar)
27.5 psi
(517 mbar)
150.00 psi
(10,34 bar)
0 psia
(0 bar)
–14.70 psig
(–1.01 bar)
3 40.0 psi
(2,76 bar)
300.00 psi
(20,7 bar)
0 psia
(0 bar)
–14.70 psig
(–1.01 bar)
Model Output protocols available
Rosemount 2088 4–20 mA dc/Digital HART (output code S)
1–5 Vdc Low Power (output code N)
Rosemount 2090F 4–20 mA dc/Digital HART (output code S)
Rosemount 2090P 4–20 mA dc/Digital HART (output code S)
