Rosemount 2088 - Dimensional Drawings

Specifications and Reference Data
79
Specifications and Reference Data
March 2017
Reference Manual
00809-0100-4108, Rev CA
A.4 Dimensional drawings
Figure A-2. Rosemount 2088
Figure A-3. Rosemount 2090P 1-in. Flush Mount
A. Digital display cover A. Field terminals
B. Conduit
connection
C. Transmitter electronics
D.
1
/2–14 NPT female
connection
(1)
1. RC
1
/2 female (PT
1
/2 female), and M20 female also available as options.
A. Bracket mounting holes (
1
/4–20 UNC)
B. Nameplate
C. Certification label (located on side)
A. Weld spud
B. 3 
5
/16–18 UNC mounting holes for rotational mounting
C. Terminal connections side
D. Optional display cover
E. Transmitter circuitry side
Dimensions are in inches (millimeter).
F. Vessel wall
G. 2 
1
/4–20 UNC–2BX 0.60 deep mounting bracket holes
H. External zero/span under nameplate
I. Nameplate
J. O-ring (Viton standard)
A
5.13
(130)
A
B
C
D
4.29
(109)
4.26
(108)
A
C
B
3.85
(98)
1.30
(33)
C
D
E
B
A
5.13 (130)
4.29 (109) max.
1.03 (26.2)
1.0 (25.4)
1.05 (26.6)
1.32 (33.4)
F
G
H
I
J
0.7 (17.8)
3.85 (98)
5.73
(146)
