22
Reference Manual
00809-0100-4108, Rev CA
Configuration
March 2017
Configuration
Re-mapping using a Field Communicator
Re-mapping using AMS Device Manager
1. Right select the device and select Configure.
2. Select Manual Setup and click on the HART tab.
3. Assign Primary, secondary, tertiary, and quaternary variables under Variable Mapping.
4. Select Send.
5. Carefully read the warning and select Yes if it is safe to apply the changes.
Re-mapping using LOI
Refer to Figure 2-16 for instructions to remap the primary variable using a LOI.
Figure 2-16. Re-mapping with local operator interface
From the HOME screen, enter the Fast Key sequence
Fast Keys
2, 1, 1, 3
VIEW CONFIG
ZERO TRIM
UNITS
RERANGE
LOOP TEST
DISPLAY
EXTENDED MENU
EXIT MENU
EXTENDED MENU
CALIBRAT
DAMPING
TRANSFER FUNCT
SCALED VARIAB
ASSIGN PV
TAG
ALARM SAT VALUES
PASSWORD
SIMULATE
HART REV
BACK TO
MENU
EXIT MENU
To Next Page
