Field communicator menu trees and Fast Keys
March 2017
Reference Manual
00809-0100-4108, Rev CA
Field communicator menu trees and Fast Keys
118
 Range Values 2, 2, 2, 1 2, 2, 2, 1
 Tag 2, 2, 7, 1, 1 2, 2, 7, 1, 1
 Transfer Function 2, 2, 1, 1, 6 2, 2, 1, 1, 6
 Pressure Units 2, 2, 1, 1, 4 2, 2, 1, 1, 4
Date 2, 2, 7, 1, 5 2, 2, 7, 1, 4
Descriptor 2, 2, 7, 1, 6 2, 2, 7, 1, 5
Digital to Analog Trim (4 - 20 mA / 1-5 V Output) 3, 4, 2, 1 3, 4, 2, 1
Digital Zero Trim 3, 4, 1, 3 3, 4, 1, 3
Display Configuration 2, 2, 4 2, 2, 4
LOI Password Protection 2, 2, 6, 5 2, 2, 6, 4
Loop Test 3, 5, 1 3, 5, 1
Lower Sensor Trim 3, 4, 1, 2 3, 4, 1, 2
Message 2, 2, 7, 1, 7 2, 2, 7, 1, 6
Pressure Trend 3, 3, 1 3, 3, 1
Rerange with Keypad 2, 2, 2, 1 2, 2, 2, 1
Scaled D/A Trim (4 - 20 mA / 1-5 V) Output) 3, 4, 2, 2 3, 4, 2, 2
Scaled Variable 2, 2, 3 2, 2, 3
Sensor Temperature Trend 3, 3, 3 3, 3, 3
Switch HART Revision 2, 2, 5, 2, 4 2, 2, 5, 2, 3
Upper Sensor Trim 3, 4, 1, 1 3, 4, 1, 1
7 Long Tag 2, 2, 7, 1, 2
7 Locate Device 3, 4, 5
7 Simulate Digital Signal 3, 5
Table C-1. Device revision 9 and 10 (HART7), DD revision 1 Fast Key sequence
Function
Fast Key sequence
HART 7 HART 5
