Rosemount 2088 - Page 124

Field communicator menu trees and Fast Keys
March 2017
Reference Manual
00809-0100-4108, Rev CA
Field communicator menu trees and Fast Keys
114
Figure C-2. Field Communicator menu tree: configure - guided setup
Note
Selections with black circle are only available in HART Revision 7 mode. Selection will not
appear in HART Revision 5 DD.
Home
1 Overview
2 Configure
3 Service Tools
Configure
1 Guided Setup
2 Manual Setup
3 Alert Setup
Scaled Variable
1 SV Data Points
2 SV Units
3 SV Transfer Function
4 SV Linear Offset
5 SV Cutoff mode
6 SV Low Cutoff
7 Scaled Variable
Configure Burst Mode
1 Burst Message 1
2 Message 1 Content
3 Message 1 Variables
Basic Setup
1 Device Tagging
2 Units of Measure/Damping
3 Variable Mapping
4 Analog Output
5 Alarm/Saturation Values
Device Tagging
1 Tag
2 Long Tag
3 Description
4 Message
5 Date
Guided Setup
1 Basic Setup
2 Zero Trim
3 Configure Display
4 Scaled Variable
5 Configure Burst Mode
Configure Display
1 Pressure
2 Scaled Variable
3 Sensor Temperature
4 Percent of Range
5 Analog Output
6 Review Parameters at Start-up
Variable Mapping
1 Primary Variable
2 Second Variable
3 Third Variable
4 Fourth Variable
Analog Output
1 Primary Variable
2 Upper Range Value
3 Lower Range Value
Message 1 Variables
1 First and Trigger Variable
2 Second Variable
3 Third Variable
4 Fourth Variable
Units of Measure/Damping
1 Units of Measure
2 Damping
Units of Measure
1 Pressure
2 Sensor Temp Units
Alarm/Saturation Values
1 Alarm Direction
2 High Alarm
3 High Saturation
4 Low Saturation
5 Low Alarm
6 Config Alarm/Sat Values
