Calibration accuracy
P8 0.1% accuracy to 10:1 turndown ★
Typical model number: 2090F G 2 S 2D E 1
Table A-4. Rosemount 2090P Pulp and Paper Pressure Transmitter Ordering Information
The starred offerings (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject to
additional delivery lead time.
Model Product description
2090P Pulp and Paper Pressure Transmitter
Transmitter type
A Absolute ★
G Gage ★
Pressure ranges (range/minimum span)
Rosemount 2090PG Rosemount 2090PA
1 -14.7 to 30 psi/1.5 psi (-1,01 to 2,1 bar/103 mbar) 0 to 30 psia/1.5 psi (0 to 2,1 bar/103 mbar) ★
2 -14.7 to 150 psi/7.5 psi (-1,01 to 10,3 bar/517 mbar) 0 to 150 psia/7.5 psi (0 to 10,3 bar/517 mbar) ★
3 -14.7 to 300 psi/40 psi (-1.01 to 20,7 bar/2,8 bar) 0 to 300 psia/40 psi (0 to 20,7 bar/2,8 bar) ★
Output
S 4–20 mA dc/digital HART Protocol
Material of construction
Process connection Isolating diaphragm Oil fill
22 316L SST 316L SST Silicone ★
Process connection
A 1
1
/2-in. threaded, no weld spud, 1
1
/2-in. PTFE gasket ★
C 1
1
/2-in. threaded, 316L SST weld spud with stress isolation and PTFE gasket ★
D 1-in. flush mount ★
G 1-in. flush mount with weld-on nipple ★
Conduit entry
1
1
/2–14 NPT ★
2 M20 1.5 female ★
Options (include with selected model number)
Extended product warranty
Table A-3. Rosemount 2090F Pressure Transmitter Ordering Information
The starred offerings (★) represent the most common options and should be selected for best delivery. The non-starred offerings are subject to
additional delivery lead time.
