Cubis
®
MCA Operating Instructions 11
Device Description
3 Device Description
3.1 Device Overview
1
2
3
4
7
6
5
Fig. 1: Precision balance (example)
Pos. Name Description
1 Manufacturer’s
ID label
Not depicted
2 Leveling foot Depends on model: Not adjustable, is screwed in for
leveling.
3 Weighing module
4 Leveling foot Motorically or manually adjustable
5 Control unit
6 Operating display Touchscreen
7 Level
