Cubis
®
MCA Operating Instructions 25
Operating Concept
Symbol Name Description
[Quit] button Quits the active application and opens the Print Memory display.
[Confirm] button Confirms the current display and initializes the next step.
[Save] button Saves the weight value and sends it to the print memory.
[Print memory] button Opens the Print Memory display.
[Print] button − If the Print Memory is displayed: Exports the saved print orders via the
integrated data interfaces.
g
[Unit change] button − Toggles between the weight units and the resolution.
− Accesses the “Unit change” function menu.
[Restart] button If an application is active: Deletes the saved values and restarts the
application.
[Report] button If an application is active, e.g. density determination: Displays a report
about the progress of the application.
[Result report] button If an application is active, e.g. density determination: Displays a report
about the result of the application.
4.10 Displays in the Operating Display
Symbol Name Description
[Leveling] display Indicates that the device is not leveled.
[Print memory] display Indicates that the elements are located in the print memory.
g
[Unit symbol] display Indicates the set weight unit, e.g. [g] for “grams”.
Gross
[Result] display Indicates whether the weight value being displayed is a gross value or the
result of an application.
[Invalid weight value] display − Together with the unit,
the display shows the calculated weight value of an application, e.g.
for the “Totalizing” application.
The displayed weight value is less than the specified minimum weight.
− For conformity-assessed devices without unit display:
− Negative gross value
− The device has not yet reached the necessary operating tempera-
ture to accurately determine the weight.
− The device is not leveled.
− The device requires the isoCAL function to be executed.
