20 Cubis
®
MCA Operating Instructions
Operating Concept
4.6 Status Center
1 2 3 3 4 5
Fig. 6: Status Center (example)
Pos. Name Description
1 Messages Displays information, warning, and error messages.
2 Leveling status Displays the status of the level.
3 Status for the device Displays the general device information.
4 Calibration and adjustment report Displays the data for the last adjustment and calibration.
5 Climate data status Displays the data from the optional climate module.
