Cubis
®
MCA Operating Instructions 39
Installation
5.7 Positioning the Weighing Pan and Associated Components
Procedure
t Place the pan support down on the retainer, diagonally to the weighing module,
and apply gentle pressure.
t Carefully turn the pan support clockwise until the two buttons engage.
y The pan support is now attached.
t Place the shield ring (2) on the weighing module (3).
t Place the weighing pan (1) on the pan support.
5.8 Acclimatization
When a cold device is brought into a warmer area: The temperature difference can
lead to condensation of humidity in the device (moisture formation). Moisture in
the device can lead to malfunctions.
t Allow the device to acclimatize for approx. 2 hours at the installation site.
Ensure that the device is disconnected from the power supply during that time.
1
2
3
