38 Cubis
®
MCA Operating Instructions
Installation
Requirements
The weighing pan and the associated components have not been set up.
Procedure
t Turn over the device and place on a soft surface.
t Remove the hook for below-balance weighing (1) from the retainer on the
underside of the base of the device.
t Pull out the cover (2) of the below-balance weighing equipment.
t NOTICE Damage to the device from cross-threading! Ensure that the hook for
below-balance weighing is inserted straight into the thread opening (1).
t Set up the device on the weighing table with recess. The hook for below-balance
weighing may not touch the floor.
t Install a draft protection shield.
t Suspend the sample on the hook for below-balance weighing, e.g. with a wire.
1
2
1
