Sartorius Cubis MCA10202S Series User Manual

Cubis
®
MCA Operating Instructions 53
System Settings
7.5.10 Parameters in the “Connections / Interfaces / COM-RS232 Interface” Menu
Parameter Settings Explanation
Protocol Off* Deactivates the RS232 connection.
SBI Enables SBI communication. The data is output to a PC or control unit.
Enables the use of ESC commands from a PC to control the basic balance
functions with ASCII protocol.
xBPI Extended range of commands to control numerous balance functions with
binary protocol for direct communication with the weighing module.
Log communication Off* Deactivates the automatic data recording for this interface.
On Activates the automatic data recording for this interface.
Baud rate 600 baud Sets the baud rate to 600 baud.
1200 baud Sets the baud rate to 1200 baud.
2400 baud Sets the baud rate to 2400 baud.
4800 baud Sets the baud rate to 4800 baud.
9600 baud* Sets the baud rate to 9600 baud.
19200 baud Sets the baud rate to 19200 baud.
38400 baud Sets the baud rate to 38400 baud.
57600 baud Sets the baud rate to 57600 baud.
115200 baud Sets the baud rate to 115200 baud.
Data bits 7 data bits Sets the number of data bits to 7.
8 data bits* Sets the number of data bits to 8.
Parity Odd* Applies an odd parity.
Even Applies an even parity.
None Does not apply a parity.
Stopbits 1 stop bit* Sets the number of stop bits to 1.
2 stop bit Sets the number of stop bits to 2.
Handshake Software Sets the handshake protocol to software handshake.
Hardware* Sets the handshake protocol to hardware handshake.
None Does not set a handshake protocol.
* Factory setting
7.5.11 Parameters in the “Connections / Interfaces / USB-B Interface” Menu
Parameter Settings Explanation
Protocol Off* Deactivates the USB-B connection.
SBI Enables SBI communication. The data is output to a PC or control unit.
Enables the use of ESC commands from a PC to control the basic balance
functions with ASCII protocol.
SICS Enables SICS communication. The data is output to a PC or control unit.
Enables the use of commands from a PC to control the basic balance
functions with SICS protocol.
xBPI Extended range of commands to control numerous balance functions with
binary protocol for direct communication with the weighing module.
PC direct Enables data output to a spreadsheet program via a direct PC connection.
Log communication Off* Deactivates the automatic data recording for this interface.
On Activates the automatic data recording for this interface.
* Factory setting
