26 Cubis
®
MCA Operating Instructions
Operating Concept
Symbol Name Description
[Sign] display Indicates whether the value being displayed is positive or negative.
[Current page] display − Indicates that the current display is a multi-page display.
− Indicates which page of a multi-page display is being displayed
currently.
[Copy] button Indicates that data are being copied.
[Selection] display Indicates that an entry is selected in a list.
[Target value] display Displays the target value in the bar graph display.
[Factory mode] display Indicates that the device is being operated in the factory default mode.
