SeaDoo GTX 4-TEC Supercharged User Manual

Section 04 ENGINE (2-STROKE)
Subsection 07 (EXHAUST SYSTEM)
F15D06S
25 Nm (18 lbfft)
NOTE: Press the pipe support on the engine
before torquing the pipe support bolt.
25 Nm
(18 lbfft)
1 Nm
(9 lbfin)
40 Nm
(30 lbfft)
40 Nm
(30 lbfft)
6 Nm
(53 lbfin)
48 Nm
(35 lbfft)
7
3
9
5
6 Nm
(53 lbfin)
48 Nm
(35 lbfft)
4
8
2
6
25 Nm
(18 lbfft)
25 Nm
(18 lbfft)
13
12
10
11
1
15
14
smr2004-Complete Line Up 177
www.SeaDooManuals.net

SeaDoo GTX 4-TEC Supercharged Specifications

General

Seating Capacity	3
Model	GTX 4-TEC Supercharged
Displacement	1494 cc
Manufacturer	Sea-Doo
Category	Personal Watercraft
Fuel Type	Unleaded gasoline
