Section 15 SUSPENSION

Subsection 01 (DIRECT ACTION SUSPENSION)

DIRECT ACTION SUSPENSION

XP DI Models

F08Q07S

34 Nm

(25 lbfft)

10 Nm

(89 lbfin)

34 Nm

(25 lbfft)

Loctite 243

smr2004-Complete Line Up 711

www.SeaDooManuals.net
