Section 04 ENGINE (2-STROKE)

Subsection 06 (ROTARY VALVE)

ROTARY VALVE

717 and 787 RFI Engines

F00D26T

20 Nm

(15 lbfft)

Molykote

111

717 engines

20 Nm

(15 lbfft)

9 Nm

(80 lbfin)

787 RFI engines

Anti-seize

lubricant

Formula XP

Injection Oil

Loctite

243

smr2004-Complete Line Up 153

www.SeaDooManuals.net
