Section10FUELSYSTEM

Subsection 03 (CARBURETOR)

CARBURETOR

For fuel system on RFI, DI and 4-TEC models, refer to appropriate ENGINE MANAGEMENT section.

Mikuni BN-40i

F17F04S

Loctite

243

Loctite

243

20 Nm

(15 lbfft)

Synthetic

grease

smr2004-Complete Line Up 519
