Section 11 LUBRICATION SYSTEM (2-STROKE)

Subsection 01 (OIL INJECTION SYSTEM)

OIL INJECTION SYSTEM

GTI Models

F17G03S

27 Nm

(20 lbfft)

3.5 Nm

(31 lbfin)

3.5 Nm

(31 lbfin)

1.2 Nm

(11 lbfin)

Dielectric

grease

smr2004-Complete Line Up 529
