Section10FUELSYSTEM
Subsection 01 (FUEL CIRCUIT)
FUEL CIRCUIT
GTI and GTI LE (carburetor-equipped) Models
F17F02S
17
1.2 Nm
(11 lbfin)
1
18
2 Nm
(18 lbfin)
3 Nm
(27 lbfin)
14
4
3
1.2 Nm
(11 lbfin)
1
2
22 Nm
(16 lbfft)
16
4 Nm
(35 lbfin)
15
16
13
19
12
8
19
6
1
1
1.2 Nm
(11 lbfin)
Engine
9
11
10
3 Nm
(27 lbfin)
Body
4 Nm
(35 lbfin)
smr2004-Complete Line Up 499
www.SeaDooManuals.net

SeaDoo GTX 4-TEC Supercharged Specifications

General

Seating Capacity	3
Model	GTX 4-TEC Supercharged
Displacement	1494 cc
Manufacturer	Sea-Doo
Category	Personal Watercraft
Fuel Type	Unleaded gasoline
