Section13PROPULSION

Subsection 04 (VARIABLE TRIM SYSTEM)

VARIABLE TRIM SYSTEM

RXP Models

F16J01U

7 Nm

(62 lbfin)

20 Nm

(15 lbfft)

Loctite

Primer N

5 Nm

(44 lbfin)

3 Nm

(27 lbfin)

Synthetic

grease

7 Nm

(62 lbfin)

Dielectric

grease

7 Nm

(62 lbfin)

Loctite

243

20 Nm

(15 lbfft)

Synthetic

grease

Loctite

Primer N

smr2004-Complete Line Up 679
