SeaDoo GTX 4-TEC Supercharged - Pto Housing;Magneto

Section 05 ENGINE (4-TEC)
Subsection 05 (PTO HOUSING/MAGNETO)
PTO HOUSING/MAGNETO
R1503motr366S
10 Nm
(89 lbfin)
Oil
Loctite 243
10 Nm
(89 lbfin)
3
4-TEC
Supercharged
only
23
9
17
15
18
14
Loctite 243
10 Nm
(89 lbfin)
Loctite
243
6
7
Oil
8
20
21
12
13
19
Oil
Loctite
anti-seize
Oil
Loctite
5910
16
Loctite 243
10 Nm
(89 lbfin)
Loctite 243
12 Nm
(106 lbfin)
Oil
Loctite 243
10 Nm
(89 lbfin)
3 Nm
(26 lbfin)
Left handed thread
Oil
11
22
Oil
1
2
Loctite 243
10 Nm
(89 lbfin)
10
