SeaDoo GTX 4-TEC Supercharged User Manual

Section 12 ELECTRICAL SYSTEM
Subsection 03 (STARTING SYSTEM)
STARTER SPECIFICATION
717 and 787 RFI Engines
Nominal output 0.6 kW
Voltage 12 V
Rated time 30 seconds
Rotation
Counterclockwise (viewed from pinion side)
Weight Approx. 2 kg (4.4 lb)
No load 11.5 V20 A max. 5500 RPM
Load 8.5 V 170 A max. 2200 RPM
Performance specification at
20°C(68°F)
Stall
5 V 350 A max. 0 RPM
Battery 12 V, 19 Ah
947 DI Engines
Nominal output 8kW
Voltage 12 V
Rated time 30 seconds
Rotation
Counterclockwise (viewed from pinion side)
Weight 1.7 kg (3.7 lb)
No load 10.9 V 45 A max. 8600 RPM
Load 9 V 120 A max. 5350 RPM
Performance specification at
20°C(68°F)
Stall
2.25 V 390 A max. 0 RPM
Battery 12 V, 19 Ah
4-TEC Engines
Nominal output 0.9 kW
Voltage 12 V
Rated time 30 seconds
Rotation
Counterclockwise (viewed from pinion side)
Weight 2.5 kg (5.39 lb)
No load 11.4 V 23 A max. 8600 RPM
Load 8.5 V 140 A max. 5200 RPM
Performance specification at
20°C(68°F)
Stall
3.75 V 330 A max. 0 RPM
Battery 12 V, 30 Ah
smr2004-Complete Line Up 589
www.SeaDooManuals.net

SeaDoo GTX 4-TEC Supercharged Specifications

General

Seating Capacity	3
Model	GTX 4-TEC Supercharged
Displacement	1494 cc
Manufacturer	Sea-Doo
Category	Personal Watercraft
Fuel Type	Unleaded gasoline
