SeaDoo GTX 4-TEC Supercharged - Propulsion; Jet Pump

Section13PROPULSION
Subsection 01 (JET PUMP)
JET PUMP
2-Stroke Models
F17J04S
3
80 Nm
(59 lbfft)
Loctite 518
6 Nm
(53 lbfin)
1
2
4
6
5
8
9
10
Loctite
Antiseize
11
Loctite 518
7
36
20 Nm
(15 lbfft)
XP DI
20
21
22
35
Jet pump
bearing grease
12
13
14
16
17
7.5 Nm
(66 lbfin)
3 Nm
(27 lbfin)
Pipe
sealant
15
18
19
21 Nm
(16 lbfft)
Loctite
243
All models except XP DI
32
31
33
2.5 Nm
(22 lbfin)
34
30
23
20 Nm
(15 lbfft)
29
20 Nm
(15 lbfft)
24
25
26
2.5 Nm
(22 lbfin)
29
28
27
2.5 Nm
(22 lbfin)
