Section10FUELSYSTEM

Subsection 02 (AIR INTAKE (2-STROKE))

AIR INTAKE (2-STROKE)

717 Engines

F02F2CT

10 Nm

(89 lbfin)

10 Nm

(89 lbfin)

10 Nm

(89 lbfin)

Loctite 518

Loctite

243

Loctite 243

Loctite

243

Loctite

243

Loctite

243

4.5 Nm

(40 lbfin)

20 Nm

(15 lbfft)

smr2004-Complete Line Up 511

www.SeaDooManuals.net

Default Chapter4
- Table of Contents4
