Section 11 LUBRICATION SYSTEM (2-STROKE)

Subsection 02 (OIL INJECTION PUMP)

OIL INJECTION PUMP

717 Engines

F00G03T

Loctite

243

4.5 Nm

(40 lbfin)

8 Nm

(71 lbfin)

8 Nm

(71 lbfin)

10 Nm

(89 lbfin)

Loctite

243

6 Nm

(53 lbfin)

6 Nm

(53 lbfin)

Loctite

243

5 Nm

(44 lbfin)

Synthetic

grease

smr2004-Complete Line Up 533

www.SeaDooManuals.net
