Section 11 LUBRICATION SYSTEM (2-STROKE)

Subsection 02 (OIL INJECTION PUMP)

787 RFI Engines

F07G0DS

6 Nm

(53 lbfin)

4.5 Nm

(40 lbfin)

3 Nm

(27 lbfin)

4.5 Nm

(40 lbfin)

534 smr2004-Complete Line Up

www.SeaDooManuals.net
