Section 11 LUBRICATION SYSTEM (2-STROKE)

Subsection 02 (OIL INJECTION PUMP)

947 DI Engines

Throttle cable

Oil pump

6 Nm

(53 lbfin)

6 Nm

(53 lbfin)

4.5 Nm

(40 lbfin)

Molykote

111

Loctite

243

Loctite

243

F12G08S
