Section 05 ENGINE (4-TEC)

Subsection 03 (EXHAUST SYSTEM)

EXHAUST SYSTEM

F19D02S

Loctite

518

Sealant

Loctite

5150

High

temperature

RTV sealant

11 Nm

(97 lbfin)

smr2004-Complete Line Up 209
