Section 14 STEERING SYSTEM
Subsection 01 (STEERING SYSTEM)
STEERING SYSTEM
GTI Series
F17K04S
41
6
5
5
1
3
2
4
4
12
14
13
8
18
16
15
17
9
10
11
10 Nm
(89 lbfin)
10 Nm
(89 lbfin)
Loctite 243
4 Nm
(35 lbfin)
13 Nm
(115 lbfin)
Loctite 243
5 Nm
(44 lbfin)
Loctite 243
6 Nm
(53 lbfin)
6 Nm
(53 lbfin)
Loctite
243
6 Nm
(53 lbfin)
Loctite 243
26 Nm
(19 lbfft)
7 Nm
(62 lbfin)
23
22
2.5 Nm
(22 lbfin)
2.5 Nm
(22 lbfin)
19
20
21
25
24
27
26
Carburetor-equipped
engines
7
Synthetic
grease
8 Nm
(71 lbfin)
7 Nm
(62 lbfin)
21
35
36
37
46
44
38
smr2004-Complete Line Up 685
www.SeaDooManuals.net
