SeaDoo GTX 4-TEC Supercharged - Page 680

Section 13 PROPULSION
Subsection 04 (VARIABLE TRIM SYSTEM)
XP DI Models
F08J10S
7
Synthetic
grease
8
9
10
2
3
2
13
1
14
16
2.5 Nm
(23 lbfin)
10 Nm
(89 lbfin)
15
5
6
12
5 Nm
(44 lbfin)
7 Nm
(62 lbfin)
11
Loctite
Primer N
Dielectric
grease
4
Loctite
243
20 Nm
(15 lbfft)
7 Nm
(62 lbfin)
20 Nm
(15 lbfft)
20 Nm
(15 lbfft)
Synthetic
grease
Loctite
Primer N
