Section 17 TECHNICAL DATA
Subsection 04 (RXP 4-TEC MODELS)
ENGINE RXP 4-TEC
Minimum (new) 23.010 mm (.9059 in)
Maximum (new) 23.020 mm (.9063 in)
Connecting rod small end diameter
Wear limit 23.070 mm (.9080 in)
Minimum (new) 22.99 mm (.9051 in)
Maximum (new) 23.000 mm (.9055 in)Piston pin diameter
Wear limit 22.990 mm (.9051 in)
Piston pin bore clearance Wear limit 0.080 mm (.0035 in)
Minimum (new) 31.98 mm (1.2591 in)
Maximum (new) 32.000 mm (1.2598 in)Balance shaft journal diameter
Wear limit 31.950 mm (1.2579 in)
Balance shaft radial clearance Wear limit 0.07 mm (.0028 in)
Minimum (new) 0.02 mm (.0008 in)
Balance shaft axial clearance
Maximum (new) 0.25 mm (.0098 in)
Minimum (new) 9.960 mm (.3921 in)
Maximum (new) 10.0 mm (.3937 in)
Supercharger shaft driven plate journal depth
Wear limit 9.700 mm (.3819 in)
Minimum (new) 11.0 mm (.4331 in)
Maximum (new) 11.050 mm (.4350 in)Supercharger drive gear thickness
Wear limit 10.500 mm (.4134 in)
Minimum (new) 6.900 mm (.2717 in)
Maximum (new) 7.100 mm (.2795 in)
Supercharger lock washer thickness
Wear limit 6.600 mm (.2598 in)
ADDITIONAL INFORMATION:
ELECTRICAL RXP 4-TEC
Magneto generator output 360W@6000RPM
Ignition system type DI (Digital Induction)
Ignition timing Not adjustable
Make and type NGK DCPR8E
Spark plug
Gap
0.7 - 0.8 mm (.030 in)
Generating coil
N.A.
Battery charging coil 0.1 - 1.0
Primary 0.85 - 1.15
Ignition coil
Secondary
9.5 - 13.5 k
Engine RPM limiter setting 8000 RPM
Battery 12 V, 30 A•h
smr2004-Complete Line Up 777
www.SeaDooManuals.net

SeaDoo GTX 4-TEC Supercharged Specifications

General

Seating Capacity	3
Model	GTX 4-TEC Supercharged
Displacement	1494 cc
Manufacturer	Sea-Doo
Category	Personal Watercraft
Fuel Type	Unleaded gasoline
