| 4 - Instruction manual
Mounting the receiver on a VESA mount
The holes in the mounting frame are positioned 100 mm apart so that the mounting frame
can be mounted on any VESA 100 mount.
CAUTION
Danger from falling objects
If you mount the receiver incorrectly on the VESA mount, the VESA mount
and receiver may fall down. This can cause personal injury and damage
to property.
▷ Follow the installation and safety instructions from the
manufacturer of the VESA mount.
▷ Screw the mounting frame onto the VESA mount as shown using four suitable screws.
▷ Insert the receiver into the mounting frame as shown until you hear it click into place.
114
