| 4 - Instruction manual
Mounting the receiver on a stand
The thread in the middle of the mounting frame is suitable for mounting on a standard
microphone stand with boom arm and 3/8" thread.
CAUTION
Danger from falling objects
If you mount the receiver improperly on the stand, the stand and receiver
may tip over. This can cause personal injury and damage to property.
▷ Use a stand that is designed for a central load of 5 kg.
▷ Adjust the length of the boom arm as short as possible, as shown
in the figure.
▷ Set the height of the stand to a maximum of 2 meters.
▷ Make sure that the total weight of the stand and the mounted
receiver does not exceed 7 kg.
▷ Screw the mounting frame onto the microphone stand as shown.
▷ Insert the receiver into the mounting frame as shown until you hear it click into place.
113
