| 4 - Instruction manual

Connecting the AWM 2 / AWM 4 remote antenna to the receiver

Instead of the supplied rod antenna, you can also connect a remote antenna to

the receiver. For more information, see AWM 2 / AWM 4 remote antennas.

▷ Pay attention to the notes about antenna installation under Recommendations on

antenna mounting.
