Error and alarm messages
Diagnostics
Alarm code A3109/3110, error 109, subcode 010/011
Alarm message Pulse 1 plausibility error at digital input DI5.
Cause The configured pulse 1 voltage is not present at digital input DI5 (X81:7).
Remedy • Check configuration of the DI5 digital input according to configuration and wiring
diagram
•Check wiring
Alarm code A3111/3112, error 109, subcode 012/013
Alarm message Pulse 1 plausibility error at digital input DI6.
Cause The configured pulse 1 voltage is not present at digital input DI6 (X81:8).
Remedy • Check configuration of the DI6 digital input according to configuration and wiring
diagram
•Check wiring
Alarm code A3113/3114, error 109, subcode 014/015
Alarm message Pulse 1 plausibility error at digital input DI7.
Cause The configured pulse 1 voltage is not present at digital input DI7 (X81:9).
Remedy • Check configuration of the DI7 digital input according to configuration and wiring
diagram
•Check wiring
Alarm code A3115/3116, error 109, subcode 016/017
Alarm message Pulse 1 plausibility error at digital input DI8.
Cause The configured pulse 1 voltage is not present at digital input DI8 (X81:10).
Remedy • Check configuration of the DI8 digital input according to configuration and wiring
diagram
•Check wiring
Alarm code A3117/3118, error 109, subcode 018/019
Alarm message Pulse 2 plausibility error at digital input DI1.
Cause The configured pulse 2 voltage is not present at digital input DI1 (X81:2).
Remedy • Check configuration of the DI1 digital input according to configuration and wiring
diagram
•Check wiring
Alarm code A3119/3120, error 109, subcode 020/021
Alarm message Pulse 2 plausibility error at digital input DI2.
Cause The configured pulse 2 voltage is not present at digital input DI2 (X81:3).
Remedy • Check configuration of the DI2 digital input according to configuration and wiring
diagram
•Check wiring
Alarm code A3121/3122, error 109, subcode 022/023
Alarm message Pulse 2 plausibility error at digital input DI3.
Cause The configured pulse 2 voltage is not present at digital input DI3 (X81:4).
Remedy • Check configuration of the DI3 digital input according to configuration and wiring
diagram
•Check wiring
