Manual – MOVIDRIVE® MDX61B Safety Module MOVISAFE® DCS..B Option
69
5
Connection options of an encoder system
Installation
5.11.1 Encoder signal split boxes
Designation Description Connection Part
number
Symbol
DAE70B Encoder signal split box
for incremental encoders
(INC)
• X26: TF temperature sensor
• X70: Encoder connection
• X71: MOVIDRIVE
®
B/MOVIAXIS
®
• X72: MOVISAFE
®
UCS..B/DCS..B
1824 379 7
4916135051
DAE71B Encoder signal split box
for absolute encoders
(SSI)
• X26: TF temperature sensor
• X70: Encoder connection
• X71: MOVIDRIVE
®
B/MOVIAXIS
®
• X72: MOVISAFE
®
UCS..B/DCS..B
1824 380 0
4916138507
DAE70B
INK
9
1
8
15
M
X72
X71
X70
1
8
9
15
1
5
9
6
DAE71B
SSI
9
1
8
15
M
X72
X71
X70
1
8
9
15
1
5
9
6
