36
Manual – MOVIDRIVE® MDX61B Safety Module MOVISAFE® DCS..B Option
4
Unit structure of DCS31B
Unit Structure
4.4 Unit structure of DCS31B
1971128203
[1] Status LEDs
[2] X80: Terminal for DC 24 V voltage supply
[3] X81: Terminal for binary inputs DI1 - DI8 and pulse signals P1, P2
[4] X82: Terminal for binary outputs DO0 / DO1
[5] X83: Terminal for binary output DO2
[6] X84: Socket for TTL incremental, SIN/COS or SSI absolute encoder
[7] X85: Socket for TTL incremental, SIN/COS or SSI absolute encoder
[8] X87: Socket for parameter setting and diagnostic interface
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
DCS31B
