SEW-Eurodrive MOVISAFE DCS B Series

Manual – MOVIDRIVE® MDX61B Safety Module MOVISAFE® DCS..B Option
139
12
Technical data of SEW encoders
Appendix
12.4.2 SIN/COS encoder
12.4.3 Combination encoders Hiperface
®
and SIN/COS
12.4.4 Combination encoders RS485 and SIN/COS
12.4.5 Combination encoder SSI and SIN/COS
Type designation Supply voltage Output signal
ES1S
DC 9–26V
AC 1 V
pp
SIN/COS
(1024 increments/revolution)
ES2S
EH1S
EV1S
DC 10–30V
ES7S
EG7S
EH7S
Type designation Supply voltage Output signal
AK0H
DC 12 V
AC 1 V
pp
SIN/COS
(128 increments/revolution)
ES1H
AC 1 V
pp
SIN/COS
(1024 increments/revolution)
AS1H
ES3H
AS3H
ES4H
AS4H
EV1H
AV1H
Positive connection Hiperface
®
encoders:
•AV6H
•AF1H
•EF1H
Type designation Supply voltage Output signal
ES7W
DC 10–30V
AC 1 V
pp
SIN/COS
(2048 increments/revolution)
EG7W
AS7W
AG7W
Type designation Supply voltage Output signal
AV1Y
DC 10–30V
•AC1 V
pp
SIN/COS
(512 increments/revolution)
• SSI Gray code
(4096 × 4096 increments)
AS7Y • AC 1 V
pp
SIN/COS
(2048 increments/revolution)
• SSI Gray code
(4096 × 4096 increments)
AG7Y
