Safety functions
Integrated Safety Technology
3.2 Safety functions
This chapter describes the safety functions according to DIN EN 61800-5-2. Some
safety functions in the MOVISAFE
®
DCS..B modules have further functionalities that
exceed the definitions stipulated in the standard. In addition, further safety functions are
available on the basis of the standard. These include, for example,
• functions for drive systems prone to slip,
• functions for reading the contacts of external switching devices and
• for the safe control of a brake system.
The MOVISAFE
®
Config software selects safety functions based on the configuration,
the basic module used, and the encoder or combination of encoders. The safety func-
tions can be configured and parameterized in the logic as required.
The following table gives an overview of the maximum number of safety functions with
reference to the respective safety module.
Designation of the safety function Maximum number of the safety function
according to
EN 61800-5-2
with option DCS..B DCS21B DCS31B
ECS ECS 1 1
EMU EMU 2 2
PDM PDM 1 1
SAR - Implementation possible using SCA
SBC - Implementation using safe output
SCA PSC 7 16
SDI DMC 1 1
SEL ELC 1 1
SLA - Integrated in SEL, SLP, SCA, SSX, SLS, SOS
SLI JSS 1 1
SLP OLC 1 1
SLS MSC 4 4
SOS ZSC 1 1
SS1(c) - Implementation using timer and safe output
SS2(c) - Requires SOS
SSR - Implementation possible using SCA
SSX
1)
1) The safety function SSX can be configured as SS1(b) or SS2(b)
-1 2
STO - Implementation using safe output
