Manual – MOVIDRIVE® MDX61B Safety Module MOVISAFE® DCS..B Option
9
Error and alarm messages
Diagnostics
9.2.2 List of alarm messages
Fatal error code F9011/9012, error 108, subcode 099/100
Error message Internal CPU error.
Remedy Replace the DCS..B option and send it together with error number to SEW Service for
further inspection.
INFORMATION
An alarm displayed on MOVIDRIVE
®
B must be reset with two time-delayed reset
commands. A single reset command of MOVIDRIVE
®
B will trigger a subsequent error
in the DCS..B option.
Alarm code A2401, error 109, subcode 001
Alarm message Communication error backplane bus MOVIDRIVE
®
B.
Cause The DCS..B option does not receive any valid data from MOVIDRIVE
®
B.
Remedy • Check hardware connection to MOVIDRIVE
®
B.
• Check firmware version of MOVIDRIVE
®
B
• Remove/install DCS..B
Alarm code A3101/3102, error 109, subcode 002/003
Alarm message Pulse 1 plausibility error at digital input DI1.
Cause The configured pulse 1 voltage is not present at digital input DI1 (X81:2).
Remedy • Check configuration of the DI1 digital input according to configuration and wiring
diagram
•Check wiring
Alarm code A3103/3104, error 109, subcode 004/005
Alarm message Pulse 1 plausibility error at digital input DI2.
Cause The configured pulse 1 voltage is not present at digital input DI2 (X81:3).
Remedy • Check configuration of the DI2 digital input according to configuration and wiring
diagram
•Check wiring
Alarm code A3105/3106, error 109, subcode 006/007
Alarm message Pulse 1 plausibility error at digital input DI3.
Cause The configured pulse 1 voltage is not present at digital input DI3 (X81:4).
Remedy • Check configuration of the DI3 digital input according to configuration and wiring
diagram
•Check wiring
Alarm code A3107/3108, error 109, subcode 008/009
Alarm message Pulse 1 plausibility error at digital input DI4.
Cause The configured pulse 1 voltage is not present at digital input DI4 (X81:5).
Remedy • Check configuration of the DI4 digital input according to configuration and wiring
diagram
•Check wiring
