Typical response times
Appendix
2. Constant travel above the monitored velocity.
4033391243
2437368075
A = Alarm is triggered
v
0
= Monitored velocity (MSC)
t
R
= Response time of the DCS..B option
s
F
= Permitted distance for overspeed distance monitoring
a = Acceleration of the drive
t
DCS
= Cycle time of the DCS..B option
