SEW-Eurodrive MOVISAFE DCS B Series

Manual – MOVIDRIVE® MDX61B Safety Module MOVISAFE® DCS..B Option
59
5
Connecting binary outputs
Installation
Similar to the previous wiring example, the above sample circuit shows a single-pole
M binary output without monitoring.
1973473291
DC 24
V
DC 0 V
1
2
3
X82
4
DO0_M
1
2
X83
DO2_P
DO2_M
DO0_P
DO1_P
DO1_M
INFORMATION
The following sample circuit is not suitable for safety applications.
