Manual – MOVIDRIVE® MDX61B Safety Module MOVISAFE® DCS..B Option
6
Fieldbus connection via PROFIsafe
Startup
"F-parameter
slave" field
Layer F in the DCS21B option is shown in the "F-parameter slave" field.
"F-parameter
master" field
Layer F of the master system is shown in the "F-parameter master" field.
"Parameter slave"
field
This section provides a comparison of the parameter data stored in the DCS21B and
the values configured in the safety controller.
A "1" on green background in the "OK" column indicates identical values.
F-parameter slave
F-CRC2 flag
"0" on green
background: OK
"1" on red background:
Faulty CRC2
F-FW communication "1" on red background:
Timeout during data transmission
F-FV activated "1" on red background:
Device not in F-layer
MOVISAFE alarm "1" on red background:
Alarm message from DCS21B
CRC1 Current CRC of the parameter data.
CRC2 Current CRC of the parameter and process data.
Consecutive number Counter for valid process data.
SIL counter Counter for second fault.
F-parameter slave
Activate FV
"0" on green
background: OK
"1" on red background:
The DCS21B option has not been properly integrated
into the F-PLC program
OA-Req "1" on red background:
The DCS21B option expects re-integration
iPar-En "1" on red background:
The DCS21B option is not ready to receive data
F-parameter slave
F-Param flag1
"1" on green background:
OK
"0" on red background:
CRC 1 of parameter channel not OK.
F-Param flag2 "0" on red background:
CRC 2 of parameter channel is not OK.
F-Source Dest. Adr "0" on red background:
The F-address of the safety controller was not
detected.
F-Dest Add "0" on red background:
The F-address of option DCS21B parameterized in
the safety controller does not match the F-address of
the DCS21B option.
