11
Installing/
Uninstalling
When connecting multiple projectors without using ID
numbers (When forming a network including projectors other
than the XG-V10 Series and XG-P20X and XG-P25X
projectors)
● Up to 99 projectors can be connected.
● Up to 99 COM ports can be used.
● Daisy chain connections are not possible.
● LAN connections are not possible.
● See “Table of Functions by Model” (page 92) about the projector’s
available functions.
Connect one projector per COM port.
If you want to use the connection via the COM ports, the same number
of COM ports as the projectors is needed. If the number of COM ports
built in your PC is less than the number of projectors, purchase the
extension board (commercially available) to add COM ports to your PC.
Connecting Single Projector with PC
RS-232C connection
Refer to the
projector’s operation
manual for details.
Optional RS-232C cable (cross type)
To Next Page
