Sharp XG-P25X - Projector Setting; Multiple Projector Operation Mode

28
Multi
Projector Setting
When “Multiple Projector Operation Mode (Use ID Number)” is selected
in “Operation Mode Setting”, it is possible to add projectors manually
without using the scan setting automatic identification function. In
addition, when “Multiple Projector Operation Mode (Don’t Use ID
Number)” or “Single Projector Operation Mode” is selected, make the
respective settings at “Projector Setting”.
Multiple Projector Operation Mode
1 From the “File” menu, select “Projector Setting”.
1 Select the ID number.
2 Select the port.
3 Select the transmission speed.
4 Input the IP address.
5 Enable/disable check box
6 Select the projector model.
7 Backup function enable/disable check box
8 Backup projector selection pull-down menu
9 Apply button.
2 Select the ID number.
If selecting “Don’t use ID Number” in “Operation Mode Setting” (page
25), you don’t need to select the ID number here.
3 Select the port to which the projector is connected.
If using the RS-232C connection, select a COM port to be used from
“Port” pulldown menu.
If using the LAN connection, select “LAN”.
LAN connections are possible only with models from the XG-V10
series with the optional extension board (AN-L10T) installed.
1
2
3
4
5
6
8
7
9
