Shimadzu GC-2014 Service Manual

Chapter 2 Configuration of GC-2014
GC-2014 Service Manual
19
S221-75086-41 S221-74567-41
DET HEATER ASSY, FT, 100 V
HEATER, PT ASSY, D-FID+ 100
115 V: S221-75086-42
115 V: S221-74567-42
230 V: S221-75086-44
230 V: S221-74567-44
S221-74582-41 S221-70742-91
HEATER PT ASSY, TCD, 100
HEATER ASSY, 100 V, 200 W
115 V: S221-74582-42
115 V: S221-70742-92
230 V: S221-74582-44
230 V: S221-70742-34
S221-32577-91 S221-70740-41
PIPE ASSY, COL-TCD1
HEAT SENSITIVE
MATERIAL, TCD+
S221-32577-92
PIPE ASSY, COL-TCD2
S221-74600-41
TCD, 100 OHMS, 2014+
S221-13964-91
PIPE, BENT
S221-70043-91 S074-80383-82
TCD POWER SUPPLY ASSY
POWER SUPPLY, ZWS30-48/J
S221-70952-91 S221-34012-91
DETECTOR ADAPTER ASSY
WBC, DET ADAPTER, WITH PURGE
S221-15561-92
JOINT SET, DET ADAPTER
S221-15563-91
GRAPHITE FERRULE, FOUR
(14)
PS CABLE, TCD, DC
(15)
(17)
(20)
R, RN AXIAL, 1/2W, 3302F
TCD-2014 CELL ASSY, 100 V HOT PLATE ASSY, 2014+, 100 V
PS CABLE, AC, AUX, 2014

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
