 Check that the status is not [Flow off] or [System off].
If 0 is displayed as the valve voltage, this indicates that there is no voltage
being supplied from the control system to the valve (TFC, Total Flow
Controller) that is attempting to supply carrier gas to INJ.
(3) The pressure or the linear velocity is higher than the setting.
 Check that [P-mode I time] = "10", [P-mode P term] = "50", and [P-mode I
term] = "100".
If not, enter these values and press the pf4 key to write them in the ROM. If
the AFC for WBI is used, the above values are as follows: [P-mode I time] =
"10", [P-mode P term] = "12", and [P-mode I term] = "10".
 Check the [Offset] and [Gain] values.
The offset value is normally in the range 32,000 to 33,500 and the gain
value is normally in the range 3,000 to 6,000. If the offset value is well
outside this range, perform offset calibration. (The method is described in
the GC-2014 instruction manual.) If the gain value is well outside this range,
obtain the correct value from Shimadzu Corporation's Quality Assurance
Department. At this time, provide notification of the serial number and lot
number displayed on the side of the AFC.

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
