SICK FLOWSIC100 Flare User Manual

174 FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH
Start-up and Parameter Settings
Subject to change without notice
Field Parameter Remark
Basic
Parameters -
Analog Output
Error current
selection
Yes Fault current is output.
No Fault current is not output.
Value 1,2 3 or 21 mA
mA value to be output in "Malfunction" state (error case) (size
depends on connected evaluation system).
Maintenance
current selection
User defined value
The value entered in the "User value" field is output during
"Maintenance".
Last Measuring Value The last value measured is output during "Maintenance"
Normal measured
value output
The current measured value is output during "Maintenance".
User value
Value - LZ whenever
possible
mA value to be output in "Maintenance" state
Entry field appears only after selection of "Used Defined Value".
Analog
Output 1
Measuring point
Measuring point 1, 2
or 3
Measuring value
Flow a.c. Volume flow in actual conditions
The selected measured
variables are output on the
analog output.
Flow s.c. Volume flow in standard conditions
Mass flow
Molar mass
Velocity of gas
Velocity of sound
Live Zero
Zero point
(0, 2 or 4 mA)
Select 2 or 4 mA to ensure being able to differentiate between
measured value and switched off device or interrupted current loop.
Lower range limit
Lower measuring
range limit Physical value at live zero
Upper range
limit
Upper measuring
range limit
Physical value at 20 mA
Output check
cycle result
values
On/Off
Output of results of check cycle: On
No output of results of check cycle: Off
Set the parameters for fields "Analog output 2(3)" analog to field "Analog output
1".
